Integrated Siren! Lub teeb tswj nrog Siren Tones, Kev Xaiv Zoo dua rau koj lub teeb ci

news-1269-846

1 Txheej txheem cej luam

CJB-XXX-F-51 yog cais cov qauv hluav taws xob hluav taws xob rau tsheb. Cov khoom yog yooj yim rau nruab, zoo nkauj tsos, ruaj khov nyob rau hauv kev ua tau zoo, nrov nyob rau hauv lub suab, thiab muaj zog nyob rau hauv anti-interference muaj peev xwm.

Tus maub los muaj LED npo zaub thiab backlight qhia ua haujlwm. Ua kom koj txoj haujlwm yooj yim dua. Ua ntej siv cov khoom no, thov nyeem phau ntawv qhia kom zoo, nws yuav muab kev pab rau koj lub installation thiab siv.

2 Qauv

2.1 Sab nraud qhov ntev ntawm KZQ70 maub los (saib daim duab 1 hauv qab)

news-679-702

duab 1

2.3 CJB-XXX-F-51 Siren (saib daim duab 2 hauv qab)

news-541-430

duab 2

3 Parameters

Watts	100W		150W		200W
Rated tam sim no ntawm txhua lub voj voog	8A±0.5A	4.3A±0.5A	13A±0.5A	5.3A±0.5A	13A±0.5A	6A±0.5A
Rted ua haujlwm voltage	DC 13.5V	DC 27.2 V	DC 13.5V	DC 27.2 V	DC 13.5V	DC 27.2 V
Load impedance	8Ω		8Ω		4Ω
Suab tso zis voltage	28V ± 1V / txhua		30V ± 1V / txhua		26V ± 1V / txhua
Microphone tso zis voltage	Ntau tshaj lossis sib npaug rau 18V / txhua		Ntau tshaj lossis sib npaug rau 18V / txhua		Ntau tshaj lossis sib npaug rau 18V / txhua
Static kev khiav hauj lwm tam sim no	Tsawg dua lossis sib npaug li 200mA		Tsawg dua lossis sib npaug li 200mA		Tsawg dua lossis sib npaug li 200mA
Tsis muaj load tam sim no	Tsawg dua lossis sib npaug li 1A		Tsawg dua lossis sib npaug li 1A		Tsawg dua lossis sib npaug li 1A

4. Cov lus qhia

4.1 Cov haujlwm ntawm txhua lub pob ntawm KZQ70 maub los

Khawm icons	Cov lus qhia ua haujlwm khawm
	Ceeb toom teeb pom kev thiab Microphone input
	Qhib/tawm pem hauv ntej ntawm lub teeb ceeb toom
	Qhib/tawm tom qab ntawm lub teeb ceeb toom
	Lub teeb ceeb toom pem hauv ntej / nram qab qhib / tawm.
	Sab laug txoj kev teeb
	TXOJ KEV HLUB
	Txoj kev kaj
	1, Flash qauv 2, Ntev nias rau ntau tshaj 10 sec. rov qab mus rau default flash qauv.
	Cruise hom (Txo 50 feem pua brightness excpet sab laug txoj kev, txoj kev txoj cai thiab nqis, yog li ntawd yog cov cim.)
	Traffic advisor
	"Horn" suab
	"Siren" suab
	Tones xaiv: Nias luv los xaiv cov suab. Ntev nias rau xauv thiab qhib lub suab.
	Microphone: Nias los tham
	Volume plus Siren tones: nias Microphone: Nias lub microphone dua li nias nws.
	Ntim - Siren tones: nias Microphone: Nias lub microphone dua li nias nws.
	Fais fab rau / tawm
